The 980nm infrared laser diode module is mainly used in industrial processing for high-precision positioning, collimation, marking pretreatment and micro-processing of specific materials. With its infrared band characteristics and stable performance, it plays an important role in the field of precision manufacturing. It applies an import 980nm semiconductor infrared laser diode and a qualified optic lens inside a durable metal housing tube, after easy connects with an external electric power source and proper installation or integration with night version device or equipment, this 980nm infrared dot laser assures high precision, high stability and good direction IR dot positioning results for multiple industrial processing works effectively.
In practical industrial processing works, 980nm infrared laser diode module is operating differently from any other visible laser device or manual dot projecting tool etc. It has good featured advantages of high concealment and no visual interference. This 980nm wavelength belongs to the near infrared band, which is invisible to the naked eyes and will not cause visual interference to operators. It is especially suitable for production lines that require manual auxiliary monitoring to avoid the influence of visible light on observation. Every time 980nm infrared dot laser alignment tool gets constant power source from 5V, 9V 1000mA DC power supply, it begins to work with high penetration IR laser light source to some of non metallic materials, such as plastics and composite materials, which can be used for internal defect detection or deep micro-processing of materials. At the same time, the energy concentration facilitates focusing into a tiny spot.
When 980nm infrared laser diode module applies APC, ACC driving circuit board design inside a durable anodized aluminum alloy housing tube, it bears various harsh working occasions, such as dust, moisture or water vapor etc. Being made with sealed packaging design, it can maintain stable infrared laser beam and infrared reference dot projection in dusty workshops with large temperature differences (some modules support -10~60℃). The extending serving lifetime of infrared dot laser can reach as long as more than 8,000 hours. It gets less output power fluctuation, low performance attenuation, and fulfills the needs of industrial continuous production.
Besides the adoption of a qualified glass coated lens and adjustable focus optic lens, this near wavelength 980nm infrared laser diode module also gets high high circularity of the spot, small divergence angle (divergence angle of some single-mode modules ≤ 1mrad), after collimation, the infrared laser beam can be kept parallel over a long distance (several meters to tens of meters), and the positioning accuracy can reach within 0.1mm. 980nm infrared dot laser alignment always maintains high electro-optical conversion efficiency and short start-up response time, can cooperate with automation equipment to achieve fast switch control, and adapt to the dynamic positioning requirements of high-speed production lines. Owing to its ultra compact structure design, it enables easy carrying, convenient and direct integration with robotic arms, conveyor belts, processing machine tools and other equipment without complex external debugging.
Specific applications in industrial processing
Precision positioning and calibration: In mechanical assembly and automated production lines, 980nm infrared laser diode module is operated as a high-precision reference light source, which provides non-contact positioning reference for the alignment of mechanical parts, guide rail calibration, equipment installation, and ensures that the assembly accuracy of parts reaches the micron level.
Laser welding/cutting assistance: In the micro-welding or fine cutting of thin sheet metal and electronic components, 980nm infrared alignment laser assists in positioning welds or cutting paths, and cooperates with high-power laser equipment to improve processing accuracy, especially suitable for the processing of tiny parts (such as electronic chip pins and precision gears).
Material micro-processing pretreatment: infrared laser light source is applied for surface modification or local heating pretreatment of ceramics, glass, polymer materials, etc., to provide precise energy focusing areas for subsequent processing (such as engraving and etching) and reduce processing errors.
Tag: laser diode module
High Photoelectric Conversion Efficiency 808nm Infrared Laser Diode Module
Under operation with a long wavelength of 808nm, being made with an import IR laser diode and a qualified glass coated lens inside a durable anodized aluminum alloy housing tube, it is manufactured into a professional night version used device of a 808nm infrared laser diode module. It generates invisible and intense infrared laser beam directly from an import 808nm infrared laser diode, and configured with inner thermal emitting system and constant electric power source supply. Being made with different dimension tube, after its proper installation or integration with night version device or equipment, this accessory part of a 808nm infrared dot laser enables easy reaching, high photoelectric conversion efficiency and high precision infrared reference dot indication onto multiple working occasions conveniently.
The usual use of a 808nm infrared laser diode module would be working for a quite long time with those of night version device or equipment. Comparing with visible laser devices among all spectrum, 808nm wavelength can convert more electrical energy into light energy, reduce the heat load of the whole machine, save energy and improve equipment performance. This special wavelength enables invisible laser beam emission with narrow spectrum width, and the wavelength temperature drift is small, and it can maintain a stable wavelength output power under different temperature environments so as to ensure the stability and accuracy of the equipment.
Basically 808nm infrared laser diode module has high radiation intensity and has passed lead-free certification, etc. It has strong anti-static ability and long service life, and can work stably in a variety of environments.The inner part of a metal heat sink cooling system and APC, ACC driving circuit board are cooperating well, which enables constant infrared laser beam emission and long time lasting infrared reference dot projection. It gets no effect by overheating and over current impact, and achieves long serving lifetime of more than 8,000 hours. When 808nm infrared dot laser gets low laser beam divergence, the infrared laser beam is concentrated immediately, and the light energy can be concentrated in a specific direction and area so as to achieve long distance IR dot indication and precise aiming easily.
Every time 808nm infrared laser diode module gets constant electric power source supply, it can make continuous IR laser beam emission, which is invisible to the human eye. In the fields of security monitoring, special applications etc, it can work without being noticed, improving the safety and effectiveness of the application. In practical night version precise dot measuring work, it bears wide range operating temperature, and can work in an environment of -20℃ to 60℃. The storage temperature range is -40℃ to 85℃, which can adapt to different working environment conditions. Due to its various advantages, this 808nm infrared alignment laser can be applied to multiple fields, such as medical, security, and industry, meeting the needs of different industries, and has high versatility and practicality. Whenever users are aware of potential thermal energy hurt from IR laser light radiation and reflection, after proper wearing of infrared laser safety goggles, it just assured easy, secured and no danger measurement for all night version fields conveniently.
Performance Advantages of 980nm Infrared Laser Diode Module
When dot alignment work is processing under all night version illumination field, it is a quite efficient job for users to operate a long wavelength made device of a 980nm infrared laser diode module. It can produce high power infrared laser light source so as to meet application scenarios with high requirements for optical power, such as industrial processing and long distance lighting work. On the basis of constant electric power source supply and practically used thermal emitting system inside its durable housing tube, this infrared dot laser enables constant infrared laser light source generation, and ultra clear and stable infrared dot generation in long time use.
Among all lasers of optical spectrum, infrared laser diode module with the wavelength of 980nm is relatively stable and is less effected by environmental factors, which ensures performance consistency under different working conditions. Being made with an import 980nm infrared laser diode within different output power range of 5mW to 500mW, and high power up to 600mW to 1000mW, it gets basic equipment of thermal emitting type of a metal heat sink cooling system inside its high duration anodized aluminum alloy housing tube. This 980nm infrared dot laser is performing well with good laser beam stability and ultra long time infrared reference dot projection as long as 10 hours per day.
According to the adoption of a qualified glass coated lens, this 980nm infrared laser diode module enables high collimation and focusing infrared laser beam emission in distance. In addition, owing to special use of adjustable focus optic lens, high energy density infrared laser light source is immediately concentrated, thus it achieves increasing high precision and high brightness infrared reference dot projection in distance. It is quite conducive to precise operation in medical and scientific research fields.
After easy connects with an AC/DC adapter, this long wavelength 980nm infrared laser can be turned on and off immediately, which just gets no limitation by work distance, lasting time or other harsh working environments as well. It can meet the needs of high speed IR laser beam modulation and pulse working modes, and is suitable for optical communications and other scenarios with high requirements for signal transmission speed.
Prospects of 980nm infrared laser diode module:
980nm infrared laser light source is used as a key pump source, which is playing an important role in the optical fiber communication system, helping to achieve high data transmission rate and long transmission distance.
Medical field: in the filed of laser surgery, physical therapy and other laser medical treatment, 980nm laser is expected to be more widely used used due to its specific absorption and penetration characteristics in biological tissues, providing more accurate and effective means for disease treatment.
Industrial manufacturing field: In industrial manufacturing processes such as metal processing and 3D printing, 980nm infrared laser modules can be used for fine processing and surface treatment of materials. As the manufacturing industry develops towards high precision and intelligence, its application space will continue to expand.
Autonomous driving and robotics field: As one of the light sources of laser radar, 980nm infrared laser diode module can provide high-precision environmental perception information for autonomous driving vehicles and robots. With the rapid development of autonomous driving technology and the robotics industry, its market demand is expected to grow significantly.
Medical Field Used 808nm Infrared Laser Diode Module
In current time laser medical therapy work fields, on the basis of high density infrared laser light source emission, the real use of a long wavelength 808nm infrared laser diode module always makes sure of highly clear and accurate infrared reference dot indication for various treatment and surgery fields. It applies an import 808nm infrared laser diode and a qualified optic lens inside its durable housing tube. When it is used as an accessory part of laser medical treatment device or equipment, not limited by work distance, it is providing excellent dot indication and positioning results for all laser medical and surgery fields constantly.
This 808nm infrared laser diode module gets high penetration infrared laser light source emission from long wavelength of 808nm, and the tissue absorbs less of it. In practical medical treatment, it has got good tissue penetration, which can achieve deep tissue imaging, photothermal therapy, etc., and avoid the trauma of traditional surgery. Employed by an import 808nm infrared laser diode within 5mW to 400mW and high power range of 500mW to 1000mW, this infrared dot laser is also making highly clear infrared dot alignment within long extending distance of 50 meters far away.
When it applies a qualified glass coated lens in front of beam aperture, 808nm infrared laser diode module is working well with high penetration and high density infrared laser light source generation at various work distances. Owing to its low beam divergence angle, it emits ultra compact size and precise infrared reference dot generation onto tissue or skins. IR laser dot destroy the hair follicles and achieve hair removal, and causing less damage to the surrounding normal tissues. After its proper installation and integration with laser treatment device or equipment, it is able to make ultra easy and convenient use for laser hair removal, tumor treatment, tissue deep penetration, and pain reliving etc.
When 808nm infrared laser diode module applies APC, ACC driving circuit board, whatever output power it is selected, it is performing well with constant output power and electric current supply, and reduced possibility of tube burning out or damage. It gets superior nice thermal emitting, and no effect by increasing temperature and electric current impact as well. In practical laser medical treatment work, any time it brings potential thermal energy hurt to human eyes and skin, this infrared alignment laser should only be used with proper wearing of infrared laser safety goggles, it just makes easy and secured measurement and positioning results in use effectively.
Advanced Use of 795nm Infrared Laser Diode Module
The genuine use of a 795nm infrared laser diode module projects visible infrared laser beam to human eyes, thus it gets superior advantages in those of concealed operation fields. It applies a qualified semiconductor IR laser diode and a qualified optic lens, configured with a high duration housing tube, it is able to work with ultra high energy density infrared laser beam radiation, ultra clear and precise infrared reference dot indication and measurement for all night version fields effectively.
In practical night version precise dot measuring works, 795nm infrared laser diode module gets longer wavelength than visible optical spectrum, thus it only allows proper use under dark environments and night version field. It applies a qualified glass coated lens and adjustable focus optic lens inside the durable anodized aluminum alloy housing tube. When it generates high photoelectric ability and high transmittance infrared laser light source, after getting low beam divergence angle, it keeps work with highly focused and low energy consumption infrared laser light source emission.
Within wide range operating temperature, and other harsh working occasion, 795nm infrared laser diode module still keeps work with long time lasting and highly stable infrared laser beam emission. It can improve dot alignment accuracy greatly. Owing to its narrow spectral line width, it can provide high spectral resolution and low noise level infrared laser light source generation for all night version illumination fields effectively.
In a large variety of materials and environments processing works, it has got wide application potential in medical, industrial detection and other fields. This 795nm infrared laser diode module gets featured advantages of good penetration and scattering characteristics. After its correct use of output power and operating voltage electric power source supply, it enables high quality infrared laser beam emission, and high stability infrared reference dot indication during laser light transmission.
Applications:
Medical field: being used as a dot positioning or indicator light source in some medical instruments, it help doctors perform surgery or treatment operations accurately. 795nm infrared laser light source is also working with skin treatment and diagnostic equipment for phototherapy and skin disease detection.
Industrial field: used for calibration and positioning in precision instrument manufacturing to provide an accurate benchmark for the production process. In industrial detection, 795nm infrared laser dot is used for material surface defect detection. By utilizing its high energy density and good infrared laser beam quality, it can display tiny flows on the surface of the material clearly.
Communication field: near infrared laser beam can be used as a signal light source to achieve high speed, high bandwidth data transmission in some specific short distance optical communication fields.
Scientific research: it is often used in experiments such as spectrum analysis and laser interferometry, providing professionals or scientists with stable and high precision infrared light source, which helps to conduct various physical, chemical, biological and other research.
808nm Infrared Laser Diode Module Used for Scientific Experiment
Comparing with any other visible laser devices, 808nm infrared laser diode module is in the near infrared region, and has a very good penetration in biological tissues, atmosphere and other media etc. Being made with a qualified semiconductor laser diode and qualified glass coated lens inside its compact structure tube, it is able to work with ultra fine infrared laser beam emission and high energy concentration. IR laser light can be used for in vivo imaging, atmospheric optics and other research, and can obtain information via the inside of the medium.
This invisible 808nm infrared laser diode module applies a qualified glass coated lens, it enables high transmittance and high density infrared light source emission. Owing to its low beam divergence, it is only projecting a quite small size infrared reference dot at various work distances. This 808nm wavelength has low absorption and scattering in many materials, which can reduce the energy loss of the IR laser light during transmission, thus achieves more accurate spectroscopy research of the materials.
Cooperating with an adjustable focus optic lens, after quite easy screw of laser beam aperture part, this 808nm infrared laser diode module enables high concentration infrared laser light projection, and efficient conversion of ultra bright and compact size infrared reference dot projection at long work distance. Featured by good directivity, in experiments that require high precision dot positioning and measurement, such as atomic optics and quantum physics experiments, 808nm infrared dot laser can accurately act on the target area. in experiments that require high energy density, it can produce obvious optical effect for nonlinear optical experiments, light-matter interaction research.
Owing to the special use of APC, ACC driving circuit board inside the tube, within wide range output power of 5mW to 400mW, 808nm infrared laser diode module keeps stable output power supply, and maintains small power fluctuation during long term operation. It provides stable infrared laser light source for spectral measurement, laser interference experiments with stable infrared laser light source guarantee, and enables great improvement of the accuracy and success rate of the experiment.
According to the use of ultra compact and durable structure design, this accessory part of 808nm infrared laser diode module enables quite easy installation and adjustment of both of IR dot diameter and emitting direction, thus achieves high accuracy and no barrier dot positioning for various scientific experiment and researches. Further more, when laser users are aware of powerful infrared laser radiation and potential thermal energy hurt to eyes, after avoiding eye exposure to beam aperture, infrared alignment laser assures easy, secured and low production cost use for all night version fields.
Constant Dot Aligned 5mW to 400mW 808nm Infrared Laser Diode Module
Not the same as any other visible laser devices, once users are trying to make ultra clear dot indication for all kinds of night version illumination work fields, it is just a much preferred choice for users to operate a longer wavelength made device of a 808nm infrared laser diode module. It keeps work with intense and powerful infrared laser radiation at long extending distance. On condition that it makes advanced use of qualified optic lens and thermal emitting system inside a high duration metal housing tube, only after its proper mounting onto those of night version machine or device, this 808nm infrared dot laser is able to bring users quite nice infrared laser light source and ultra clear infrared reference dot indication for all night version illumination fields constantly.
Comparing with a simple IR laser pointer only used for temporary dot positioning work, the genuine use of a 808nm infrared laser diode module would be working for even longer time. Besides the use of an import 808nm infrared laser diode, it has been equipped with a metal heat sink cooling system inside a highly durable anodized aluminum alloy housing tube. The whole process of infrared laser dot alignment work is bearing wide range operating temperature, and multiple harsh working occasion, including mechanical moving, shocking or calibration etc.
On the basis of a high quality glass coated lens and glass window in front of laser beam aperture, in order to avoid laser light decay or blur in continuous use, this 808nm infrared laser diode module also passes through a series of strict laser beam stability test and aging preventing test. Only if it makes continuous infrared reference dot projection within 10 hours per day, it still maintains up to 85% laser beam stability. Within wide range output power of 5mW to 400mW, this 808nm infrared dot laser is not simply used for close distance, but also making sure of ultra clear and precise IR dot projection as long as 50 meters.
Being made APC, ACC driving circuit board, whatever output power it is selected, this 808nm infrared laser diode module is still working well with constant output power and electric current supply. It gets reduced possibility of tube burning out or damage, and long serving lifetime of more than 8,000 hours. When it is operating with correct output power, and making proper screw of adjustable focus optic lens, this infrared alignment laser gets highly concentrated IR laser light source emission and increasing accuracy and brightness infrared dot projection at greater distance. When users would prefer to take active laser safety measures and wear correct infrared laser safety goggles, it still brings users easy, free and secured IR dot alignment for all working occasion effectively.
Constant Measuring Tool of DC Power 980nm Infrared Laser Diode Module
When users are in need of ultra clear and precise dot projection for all night version illumination work fields, it is not workable at all to rely on any manual dot projecting tool. At the same time, under operation with constant technical innovation of a 980nm infrared laser diode, it has been made into a quite practically used device of a 980nm infrared laser diode module. It is working well with high density and highly powerful infrared laser light source emission at long extending distance. Once this 980nm infrared dot laser is cooperating with other night version device and making proper adjustment to correct position, it brings users quite nice dot aligning solution for all night version illumination work fields constantly.
The genuine dot alignment with a 980nm infrared laser diode module is always working for a quite long time, it should have to be made with even better thermal emitting than a formally used IR laser pointer. The advanced use of an import 980nm infrared laser diode has just assured increasing laser beam stability. In addition, on consideration of its good thermal stabilization, it has been made with a metal heat sink cooling system inside a high duration anodized aluminum alloy housing tube. Only if 980nm infrared dot laser makes constant IR dot projection within 10 hours per day, it just achieves high level of laser light cycling use and highly reliable performance in proper use.
In a large variety of night version precise dot positioning work fields, on the basis of a qualified glass coated lens, this 980nm infrared laser diode module is performing well with high photoelectric ability and high density IR laser light emission. Owing to its strict laser beam stability test and aging preventing test up to 24 hours, once it is operating properly by skilled users or professionals, after its correct use of output power and different operating voltage DC power supply, this direct diode emission made 980nm infrared dot laser just brings users a no mistake measurement for infrared laser sight, IR laser communication, laser medical therapy, intelligence system, and lab experiment work etc.
Designed with APC, ACC driving circuit board, within wide range output power of 100mW to 500mW, this 980nm infrared laser diode module is performing well with the most reliable and stable IR dot generation at long extending distance. It gets no effect by increasing temperature and serious electric current impact, and obtains long serving lifetime of more than 8,000 hours. For the most important of all, when users are taking active laser safety measure and wearing correct laser safety goggles, this infrared alignment laser just makes easy, free and secured dot indication for all working occasions.
How to make correct selection of an 808nm infrared laser diode module?
In those of special night version illumination fields, in order to make sure of high precision dot indication, it should be the only one choice for users to operate a long wavelength made device of an 808nm infrared laser diode module. It keeps works with intense and invisible infrared the light source emission from an inner 808nm infrared laser diode. In practical night version precise dot measuring work fields, this 808nm infrared dot laser is always working well with other net devices. Only after its proper installation and adjustment to correct position, it just makes sure of good quality infrared laser light source emission and high precision and easy reaching infrared dot projection onto multiple working surfaces.
The usual use of an 808nm infrared laser diode module has to work for a quite long time and also maintains its stable performance in continuous use. Being made with an input 808nm infrared laser diode within 100mW to 400mW, it is not only adopting a quite durable anodized aluminum alloy housing tube, but also gets important design of a metal heat sink cooling system. In process of long lasting continuous infrared dot projection, this 808nm infrared dot laser has just got superior nice thermal emitting and thermal conductivity. It always allows constant infrared dot projection within daily operating time of ten hours per day, without any appearance of laser light decay or blur in proper use.
Being made with a qualified glass coated Lens, whatever kind of working surface it is pointing, this 808nm infrared laser diode module is working well with high transmittance and high photoelectric ability infrared laser light source emission at long extending distances. Usually it gets special use of a glass window in front part of laser beam aperture, thus this 808nm infrared dot laser is able to maintain its stable and reliable infrared reference dot projection under harsh occasion of moisture or dust etc.
As a result, when this 808nm infrared laser diode module gets proper installation onto any other machine or device, not any longer Limited by manual labor force input, it should only be selected with correct output power and proper installation to correct position. Within wide range output power of 100mW to 400mW, it should only be selected with correct output power, thus gets ideal infrared reference dot alignment accuracy within the extending distance of 100 to 1000 meters far away.
Together with electric wires extension for both of 808nm infrared laser dead module and DC power supply, it enables freely installed distance of three meters, and there is no limitation by any harsh working occasion as well. At the same time, owing to the special use of adjustable focus optic Lens design, only after its easy screw of beam aperture, this 808nm infrared alignment laser just gets the most concentrated laser light source emission and the most precise infrared dot projection in continuous use. It is just a key issue to wear correct infrared laser safety goggles, without any eye exposure to beam aperture at close distance, it just makes sure of easy and secured dot indication in all night version illumination work fields effectively.
What is an easy job with an 808nm infrared laser diode module?
Until the time users are trying to make highly precise dot projection under all night version fields, it is far more enough to reach with a simple IR laser pointer or any other manual dot projection tool at all. Nothing can be observing by human eyes directly. However, the special use of an 808nm infrared laser diode module has just brought users quite special dot measuring experiment. It applies an import IR laser diode and qualified optic lens, after its professional equipment with any other night version machine or device, this infrared dot laser is able to work with highly quality and high density IR laser light source generation. It is also able to make clear and accurate IR dot instruction for all night version lab experiment and scientific experiment works etc.
Owing to the easy connects with an AC/DC adapter, together with electric wires extension for both of 808nm infrared laser diode module and DC power supply, it allows the most convenient installation and the easiest reaching of IR dot projection onto any raw material surface. In practical precise dot measuring work fields, it is working with night version device of CCD camera, black and white camera or infrared laser camera etc. Being made with an import 808nm infrared laser diode within 100mW to 400mW, this 808nm infrared dot laser is not only making sure of high density and high concentration infrared laser light source emission, but also assuring efficient conversion of clear and precise IR dot generation at long work distance.
In a large variety of night version precise dot measuring work fields, owing to the special use of a qualified glass coated lens, this 808nm infrared laser diode module is working well with extremely clear dot indication as long as 100 to 1000 meters in continuous use. When it adopts different dimension tube diameter of 16mm and 26mm, available with highly durable anodized aluminum alloy housing tube, this infrared dot laser has just obtained the best performance under harsh occasion of mechanical moving or shocking etc.
Available with wide range output power of 100mW to 400mW, together with APC, ACC driving circuit board, this 808nm infrared laser diode module is performing well with constant output power and electric current supply. It makes long lasting dot indication, however, there is still no effect by increasing temperature and serious electric current impact as well. Whenever users are operating any output power made infrared alignment laser, it is a key issue to be aware of any powerful IR laser radiation and thermal energy hurt to eyes. When users are wearing correct infrared laser safety goggles, it brings users secured and easy dot measurement in long lasting use perfectly.
